General |
|
Topology |
Line
Interactive |
|
Configuration |
Rackmount |
|
Part
Number |
103003267-6591 |
|
Color |
Black |
|
Rating (VA/Watts) |
500/320 |
|
Efficiency |
95% |
|
Dimensions
(H x W x
D, mm) |
45 x 440
x 580 |
|
Weight
(kg) |
9 |
| |
|
Electrical
Input |
|
Connection |
(1) IEC-320-C14
|
|
Input
Voltage
Range |
± 20% of
nominal |
|
Nominal
Voltage |
220/230/240
Vac |
|
Operating
Frequency |
50/60 Hz
auto
sensing |
| |
|
Electrical
Output |
|
Nominal
Voltage |
220/230/240
Vac |
|
Output
voltage
regulation |
-10%/+6%
of
selected
nominal
voltage |
|
Output
Receptacles |
(4) IEC-320-C13
|
|
Overload
Capacity |
110% 3
min;
150% 10
cycles |
| |
|
Communications |
|
LEDs |
Four
LEDs;
UPS on,
UPS on
battery,
overload,
alarm |
|
Communication
Ports |
RS232/USB
and
X-slot |
|
Communications
Slot |
Internal
SNMP
adapter |
| |
|
Environmental
&
Standards |
|
Audible
Noise |
<40 dB @
1m |
|
Operating
Temperature |
0°C -
+40°C |
|
Safety
markings |
IEC
62040-1-1
& UL
1778 |
|
EMC
Markings |
IEC
62040-2,
EN
6100-3-2 |
|
Markings |
CE |
|
Storage
Temperature |
-15°C
-+55°C |
