| General | ||
| UPS output power rating (1.0 p.f.) | 30, 40, 50 kW | |
| Efficiency in double conversion mode | 96.7% | |
| Efficiency in Energy Saver System (ESS) | 99% | |
| Field upgradeable | Yes, up to 50 kW | |
| Inverter/rectifier topology | Transformer-free IGBT with PWM | |
| Audible noise | 55 dBA at 75% load, 60 dBA at 100% load | |
| Altitude (max) | 1000 m without derating (max 2000 m) | |
| Input | ||
| Input wiring | 3 ph + N + PE | |
| Nominal voltage rating (configurable) | 220/380, 230/400, 240/415 V 50/60 Hz | |
| Input voltage range | High +20% rectifier input, 10% bypass input Low -15% at 100% load, -40% at 50% load without battery discharge |
|
| Input frequency range | 40-72 Hz | |
| Input power factor | 0,99 | |
| Input ITHD | < 3% | |
| Soft start capability | Yes | |
| Internal backfeed protection | Yes | |
| Output | ||
| Output wiring | 3 ph + N + PE | |
| Nominal voltage rating (configurable) | 220/380, 230/400, 240/415 V 50/60 Hz | |
| Output UTHD | < 1% (100% linear load); < 5% (reference non-linear load) | |
| Output power factor | 1.0 | |
| Permitted load power factor | 0,8 lagging - 0,8 leading | |
| Overload on inverter | 10 min 102-110%; 60 sec 111-125%; 10 sec 126-150%; 300 ms > 150%. On battery mode 300 ms > 126% |
|
| Overload when bypass available | Continuous < 125%, 10 ms 1000% | |
| Battery | ||
| Battery type | VRLA | |
| Charging method | ABM technology or Float | |
| Temperature compensation | Optional | |
| Battery nominal voltage (lead-acid) | 432 V (36 x 12 V, 216 cells) | |
| Charging current limit | 22A | |
| Battery start capability | Yes | |
| Accessories | ||
| External battery cabinets with long-life batteries, external maintenance bypass switch, integrated manual bypass, MiniSlot connectivity (Web/SNMP, ModBus/Jbus, Relay) | ||
| Communications | ||
| Minislot | 3 communication bays | |
| Serial ports | Built-in host and device USB | |
| Relay inputs/outputs | 5 relay inputs and dedicated EPO 1 relay output |
|
| Compliance with standards | ||
| Safety (CB certified) | IEC 62040-1 | |
| EMC | IEC 62040-2, EMC Category C2 | |
| Performance | IEC 62040-3 | |
| Standard UPS | |||||
| Part number | Description | Rating | Full load runtime | Dimensions (WxDxH) | Weight (with battery) |
| P-105000007-013 | 93PM-30(50)-MBS-BB-6x9Ah | 30 kW | 20 min | 560 x 914 x 1876 mm | 890 kg |
| P-105000007-028 | 93PM-40(50)-MBS-BB-6x9Ah | 40 kW | 15 min | 560 x 914 x 1876 mm | 890 kg |
| P-105000007-040 | 93PM-50(50)-MBS-BB-6x9Ah | 50 kW | 10 min | 560 x 914 x 1876 mm | 890 kg |
| External Battery Cabinet | |||||
| Part number | Description | Battery | Dimensions (WxDxH) | ||
| P-105000017-002 | 93PM BAT-S 1x36 110 W (250A) | 110W 12V | 575 x 914 x 1870 mm | ||
| P-105000017-004 | 93PM BAT-S 1x36 200 W (250A) | 200W 12V | 575 x 914 x 1870 mm | ||
