General |
|
Configuration |
Desktop mini
tower |
|
Part Number |
3S550DIN |
|
Color |
Black |
|
Rating (VA/Watts) |
550/330 |
|
Dimensions (H x
W x D mm) |
86 x 140 x 335 |
|
Weight (kg) |
2.9 |
|
Warranty |
2-year warranty
on electronics
2-year warranty
on battery load
protection
guarantee |
Contents
(Ships with the
following items) |
UPS with
attached input
cord
USB Cable
User manual in
20 languages
Safety
instructions |
| |
|
Electrical Input |
|
Connection |
(1) Schuko
|
|
Input Voltage
Range |
Up to 161-284 V
(adjustable) |
|
Protection |
Resettable circuit breaker |
|
Frequency |
50/60 Hz
autoselect |
| |
|
|
Electrical
Output |
|
Voltages |
230 V (settable
to 220 V 230 V
or 240 V) |
|
Output
Receptacles |
(3) Schuko
|
(3)
Schuko surge
only |
| |
|
Battery |
| |
|
Battery Type |
Compact sealed
lead-acid
(replaceable) |
|
Battery
Replacement
Indicators |
LED |
|
Battery Test |
Yes |
|
Cold start (No
mains power) |
Yes |
|
Deep Discharge
Protection |
Yes |
| |
|
Communications |
|
Communication
Ports |
HID-compliant USB port for automatic integration with most common
operating systems (Windows XP, Vista and 7, Linux, Mac OS X), cable
supplied |
|
Environmental &
Standards |
|
Safety markings |
IEC/EN 62040-1-1, CE mark |
|
EMC Markings |
IEC 62040-2 |
|
Data Line
Protection |
Tel/fax/modem/internet/Ethernet |
|
|
|
|
Power Management
Software |
|
Option |
free download |
|
UPS Companion |
|
|
Software ideally
suited for power
management of
personal
computers (and
their associated
peripherals)
with a serial /
USB connection
to the UPS.
|
