General |
|
Power
Rating |
12 kW
per UPS
Module |
|
Efficiency |
Up to
98.6% |
|
Heat
Dissipation |
371W/1266
BTU/hr.
at 100%
rated
load |
|
Cooling |
Fan
cooled,
temperature
microprocessor
monitored;
front
air
entry,
rear
exhaust |
|
Audible
Noise,
Normal
Operation |
<60 dBA
at 1
meter |
|
Altitude |
1000
meters
(3300
ft. ASL) |
|
Input |
|
Input
Voltage |
400 Vac
|
|
Voltage
Range |
400V:
311 to
519 Vac,
phase to
phase
|
|
Frequency
Range |
50 or 60
Hz, ±5
Hz |
|
Input
Current
Distortion |
<5% with
IT loads
(PFC
power
supplies) |
|
Input
Power
Factor |
>.99
with IT
loads (PFC
power
supplies) |
|
Inrush
Current
|
Load
dependent |
|
Input
Requirements
|
Three-phase,
four
wire +
ground |
|
Bypass
Source |
Same as
input,
(single
feed) |
|
Generator
Compatibility |
Fast
sync
slew
rate for
optimum
generator
synchronisation |
|
Output |
|
Rated
Output
Voltage |
400V:
180 to
240 Vac,
Ph to N
|
|
Output
Configuration |
Three-phase,
four
wire +
ground |
|
Output
Frequency
(nominal) |
50 or 60
Hz
auto-detection
on
startup |
|
Frequency
Regulation |
0.1 Hz
free
running |
|
Load
Power
Factor
Range |
Lagging:
0.7
Leading:
0.9
|
Total
Output
Voltage
Distortion |
<3% with
IT loads
(PFC
power
supplies)
<5%
non-linear
or non-PFC
power
supplies
|
|
Battery |
|
Battery
Type |
VRLA -
AGM |
|
Battery
Runtime
(Internal) |
13
minutes
at 50%
load
4.7
minutes
at 100%
load |
|
Battery
String
Voltage |
240 Vdc |
|
Battery
Test |
Automatic
battery
test
standard
(remote
scheduling
capable).
Manual
battery
test
from
front
display |
|
Battery
Recharge
Profile |
ABM
three-stage
charging
technology
|
|
Battery
Cut-off
Voltage |
Variable
from
1.67 VPC
at <5
min.
runtime
|
|
Battery
Low
Condition |
Announced
with
alarm |
|
Extended
Battery
Capability |
Yes, add
up to
four
additional
3U
battery
enclosures
(~34 min
at 100%
load, >1
hour at
50%
load) |
|
Physical |
Dimensions
(HxWxD)
UPS |
261 (6U)
x 442 x
660 mm
|
Note:
Total
Chassis
Weight
without
batteries
or
electronics
Total
Chassis
Weight
with
batteries
or
electronics |
46 kg
140 kg |
|
Total
UPS
Weight
without
Batteries |
61 kg |
|
Total
UPS
Weight
with
Batteries |
140 kg |
|
EBM
Weight |
77 kg |
|
Communications
and User
Interface |
|
Software
Compatibility |
UPS
ships
with
Software
Suite CD |
|
X-Slot
Bays |
Two
available
for the
cards
listed
below |
|
Control
panel
LCD |
Two
lines by
20
characters
Four
menu-driven
interface
buttons
Four
status
at a
glance
LEDs
|
|
Multi-language |
English
standard;
20
languages
available |
|
Configuration
Changes |
User
capable,
firmware
auto
configures |
|
Dry
Contact
Inputs |
Two,
user
configurable |
|
Dry
Contact
Outputs |
One,
user
configurable |
|
Service |
|
Installation |
User
capable,
located
in the
IT racks |
|
Preventative
Maintenance |
User
capable,
optional
factory
service
available |
|
Corrective
Maintenance |
User
capable,
optional
factory
service
available |
|
Serviceability
Features |
Hot-swappable
batteries
Hot-swappable
electronics
module
Automated
internal
maintenance
bypass
Auto-configure
firmware
Flash
firmware
upgradeable
|
|
Certifications |
|
EMI |
IEC
62040
|
|
Surge
Protection |
ANSI
C62.41,
Cat B-3 |
|
Hazardous
materials
(RoHS) |
EU
Directive
2002/95/EC
Category
3 (4 of
5) |
|
Warranty |
|
Standard |
12
months
|
|
Warranty
Repair |
Factory
depot
repair
or
replace |
|
Options
and
Accessories |
|
Detachable
input
cord |
|
Detachable
input/output
cord
assembly |
|
Detachable
paralleling
cord
assembly |
|
Extended
Battery
Modules
(EBMs) |
|
3U
output
sub-distribution
module |
|
0U to 3U
rack
power
strips |
|
60 kW
BladeUPS
Parallel
bar |
|
Four-post
rail kit |
|
Optional
X-Slot
Communication
Cards |
|
Application |
Card |
|
WEB SNMP |
ConnectUPS-X
Web/SNMP
Card |
|
Environment
Monitoring |
EMP
Environmental
Monitoring
Probe
(requires
Web/SNMP
card) |
IBM
eServer™
(i5™,
iSeries™,
or
AS/400),
industrial
|
Relay
Interface
Card |
|
Parallel |
Hot Sync
Card |
|
Remote
Monitoring |
Modem
Card |
|
Remote
LCD
Display |
ViewUPS-X |
|
Recommended
ePDU |
|
Y032440CD100000 |
RPM -
Rack
Power
Module (BladeUPS
in,
12xC13 +
6xC19
out)
20ft
lead |
|
PW107BA0UC08 |
ePDU -
Basic
(0U,
Dual 16A
C20 in,
24xC13+
8xC19
out) use
in
addition
to RPM |
|
PW107MI0UC08 |
ePDU -
IP
Monitored
(0U,
Dual 16A
C20 in,
24xC13+
8xC19
out) use
in
addition
to RPM |
