UPS rating (0.9
power factor) |
|
kVA |
225 |
275 |
300* |
450 |
550 |
650 |
825 |
1100 |
|
kW |
202 |
247 |
240 |
405 |
495 |
585 |
742 |
990 |
|
*
Based on 0.8 p.f. |
|
General
|
|
Efficiency in
double
conversion mode
(full load) |
>94,3% |
|
Efficiency in
double
conversion mode
(half load) |
93.3% |
|
Efficiency in
Energy Saver
System (ESS) |
up to 99%
|
|
Distributed
parallelling
with Hot Sync
technology
|
5 |
|
Internal N+1
redundance
capable |
from 225 to 825
kVA |
|
Field
upgradeable |
Yes |
|
Inverter/rectifier
topology |
transformer-free
IGBT with PWM
|
|
Audible noise
|
<76 dB; <81 dB
(825 and 1100
kVA)
|
|
Altitude (max) |
1000 m without
derating (max
2000 m)
|
|
Input
|
|
Input wiring
|
3
ph + N + PE
|
|
Nominal voltage
rating
(configurable) |
220/380,
230/400, 240/415
V 50/60 Hz
|
|
Input Voltage
range |
+10% / -15% |
|
Input Frequency
range |
45-65 Hz |
|
Input Power
factor |
0,99 |
|
Input ITHD
|
less than 4,5%
|
|
Soft start
capability |
Yes |
|
Internal
Backfeed
Protection |
Yes |
|
Output |
|
Output wiring
|
3
ph + N + PE
|
|
Nominal voltage
rating
(configurable) |
220/380,
230/400, 240/415
V 50/60 Hz
|
|
Output UTHD
|
<3% (100% linear
load); <5%
(standard
nonlinear load) |
|
Output power
factor
|
0.9, 0.8 for 300
kVA |
|
Permitted load
power factor
|
0.7 lagging -
0.8 leading |
|
Overload on
inverter
|
10 min 100-110%;
30 sec 110-125%;
10 sec 125-150%;
300 ms >150%
|
|
Overload when
bypass available
|
Continuous
<115%, 20 ms
1000%
Note! Bypass
fuses may limit
the overload
capability |
|
Battery
|
|
Type
|
VRLA, AGM, Gel,
Wet Cell
|
|
Charging method
|
ABM technology
or Float
|
|
Temperature
compensation
|
Optional
|
|
Battery nominal
voltage
(lead-acid)
|
480 V (40 x 12
V, 240 cells)
|
|
Charging
current/Model
|
275 |
550 |
825 |
1100 |
|
|
Default A |
38 |
76 |
114 |
152 |
|
|
Max* A |
83 |
166 |
249 |
332 |
|
*Limited by
maximum UPS
input current
rating |
|
Dimension and
Weights |
|
225 kVA, 275 kVA,
300 kVA
|
1350 x 880 x
1880 mm (wxdxh) |
830 kg
|
225 kVA
redundant,
275 kVA
redundant,
300 kVA
redundant
|
1890 x 880 x
1880 mm
|
1430 kg
|
|
450, 500, 550
kVA |
1890 x 880 x
1880 mm
|
1430 kg
|
|
450, 550 kVA
redundant
|
2520 x 880 x
1880 mm
|
2030 kg
|
Field upgrade
module,
225, 275 or 300
kVA |
740 x 880 x 1880
mm |
600 kg
|
|
675, 825 kVA
|
3710 x 880 x
1880 mm
|
2520 kg
|
|
675, 825 kVA + 1
redundant
|
4450 x 880 x
1880 mm |
3120 kg
|
|
1100 kVA
|
4450 x 880 x
1880 mm
|
3120 kg
|
|
Accessories
|
| |
External battery
cabinets with
long-life
batteries,
X-Slot
connectivity
(Web/SNMP,
ModBus/Jbus,
Relay, Hot Sync,
ViewUPS-X remote
display),
integrated
manual bypass
for 225-550 kVA
|
|
Communications
|
|
X-Slot |
4
communication
bays
|
|
Serial ports |
1
available
|
|
Relay
inputs/outputs |
5/1 programmable
|
|
Compliance with
standards
|
|
Safety (CB
certified)
|
IEC 62040-1, IEC
60950-1
|
|
EMC |
IEC 62040-2 |
|
Performance
|
IEC 62040-3
|
