General |
|
Topology |
Online
double-conversion |
|
Configuration |
Rackmount |
|
Part
Number |
103005093-6591 |
|
Color |
Black |
|
Rating (VA/Watts) |
7500/6000 |
|
Efficiency |
>90% |
|
Dimensions
(H x W x
D, mm) |
263x430x760 |
|
Weight
(kg) |
115 |
| |
|
Electrical
Input |
|
Connection |
Hardwired - see manual for terminal block layout
|
|
Input
Cord |
Hardwired |
|
Input
Voltage
Range |
174-288
V (for
220-240
V
nominal
output) |
|
Operating
Frequency |
50/60 Hz
auto-sensing |
|
Input
Power
Factor |
0,99 |
|
Input
Current
Distortion |
< 5% THD |
| |
|
Electrical
Output |
|
Nominal
Voltage |
200 V /
208 V /
220 V /
230 V /
240 user
selectable |
|
Output
voltage
regulation |
±2%
static,
±10%
dynamic |
|
Output
Receptacles |
|
(3)
IEC-320-C19
 |
Hardwired
- see
manual
for
terminal
block
layout
|
|
Overload
Capacity |
±10% of
112 to
130% for
60 sec,
transfer
to
bypass |
| |
|
Battery |
|
Extended
Battery
Capability |
Extended
battery
modules
3U EBM |
| |
|
Communications |
|
User
Interface |
Multilingual
graphical
LCD with
blue
backlight |
|
LEDs |
(4) LEDs |
|
Communication
Ports |
1 x USB,
1 x
RS232
serial,
1 x REPO |
|
Communications
Slot |
(1)
X-Slot
communication
bay |
|
Communications
Card
Slots |
Optional:
Web/SNMP,
Modbus/Jbus,
Relay,
RS 232
cards |
|
Power
Management
Software |
Bundled
software
suite
CD;
Eaton
9140 is
HID-compliant |
| |
|
Environmental
&
Standards |
|
Audible
Noise |
< 55
dB(A) at
1,5
metres |
|
Operating
Temperature |
0°C to
40°C |
|
Safety
markings |
IEC/EN
62040-1-1,
CE, UL,
cULus,
NOM, TUV |
|
EMC
Markings |
IEC/EN
62040-2,
CE, FCC,
VCCI,
C-tick |
|
Markings |
CE, GOST |
|
Storage
Temperature |
-20°C to
+50°C
|
|
Altitude |
Operating
3000 m,
transit
15000 m |
| |
