General |
|
Topology |
Double
conversion
(on-line) |
|
Configuration |
Rack |
|
Part
Number |
68056 |
|
Rating (VA/Watts) |
5000/4000 |
|
Dimensions
(H x W x
D, mm) |
261.2 x
444.5 x
700 |
|
Weight
(kg) |
89.5 |
|
Warranty |
1 year
warranty,
including
battery,
Free
standard
replacement
for
faulty
units,
including
the
batteries |
|
Rail Kit
Included |
Yes |
|
Remote
Emergency
Power
off (REPO) |
RJ11 for
remote
emergency
power
off |
| |
|
Electrical
Input |
|
Connection |
Hardwired - see manual for terminal block layout
|
|
Input
Voltage
Range |
(- 30%;
+ 20%)
230 V |
|
Nominal
Voltage |
380/400/415V
three
phase |
|
Frequency |
50 / 60
HZ
autoselection |
|
Frequency
Range |
40-70 Hz |
|
Short
Circuit
Current |
100 A |
| |
|
Electrical
Output |
|
Voltages |
200/208/230/240
/250 V
+/- 2% |
|
Voltage
THD |
< 2% |
|
Output
Receptacles |
Hardwired - see manual for terminal block layout
|
|
Overload
Capacity |
>150%
500 ms;
150% 30
s; 125%
60 s;
110% 120
s |
|
Efficiency
(Normal
Mode) |
91% (eco
mode
97%) |
|
Output
Frequency |
50 / 60
Hz
autoselect,
frequency
converter
as
standard |
|
Load
Crest
Factor |
3:1 |
| |
|
Battery |
|
Extended
Battery
Capability |
EXB RT
battery
module
(3U) |
| |
|
Communications |
|
User
Interface |
Multilingual
LCD
display
and LEDs
for
rapid
view of
the UPS
status
and the
operating
log |
|
Communication
Ports |
6
voltage
free
contacts
DB9 2 A
48 V DC,
1 RS 232 |
|
Communications
Card
Slots |
1 slot
with
Network
Card |
| |
|
Environmental
&
Standards |
|
Operating
Temperature |
45°C for
8 Hrs
(at
nominal
output
power
for 400
V input
and 230V
out),
40°C
continuous |
|
Performance
- Safety
- EMC |
IEC
62040-1/IEC
60950/UL
1778 |
|
Safety
markings |
TÜV, GS
mark,CB,
C-Tick,CE,
IEC
68-2-6
(vibration
tests
Marine
approval) |
|
EMC
Markings |
IEC
62040-2;
EN
50091-2 |
