Anviz OC180 is wall mounted RFID time attendance. Featured in ultrathin and fashionable appearance,
OC180 adopt USA TI high speed CPU. In addition, OC180 have plug and play USB , TCP/IP networking
communication and USB flash driver up and download. With all these excellent features, OC180 will
undoubtedly become high cost performance professional RFID time attendance for small and medium enterprises.
Features:
• Extremely thin and refined design
• User friendly graphic interface
• Support multiple display and software language
• USB Plug & Play connection
• Easy TCP/IP connectivity
• Inbuilt RFID reader
• 16 different customizable time and attendance status
• 6-digit work code to calculate different job cost
• Inbuilt 1100mA chargeable battery
|
Item |
Description |
|
Algorithm |
BioNANO V10 |
|
Sensor |
AFOS300 Optical Sensor |
|
Scan Area |
22mm*18mm |
|
Resolution |
500 DPI |
|
LCD |
3"widescreen High Definition TFT display |
|
Fingerprint Capacity |
3000 |
|
Log Capacity |
50000 |
|
Identification Mode |
FP, Card, ID+FP, ID+PW, PW+Card, FP+Card |
|
Identification Time |
<0.5 Sec |
|
FRR |
0.00% |
|
FAR |
0.00% |
|
Communication Interface |
USB Device, USB Host, TCP/IP |
|
Card Reader Module |
Optional 125KHZ EM RFID, 13.56MHZ Mifare |
|
Name Display |
Yes |
|
Fingerprint Image Display |
Yes |
|
Self-defined Status |
16 customizable time and attendance status |
|
Auto Status Switch |
Yes |
|
Workcode |
6-digit |
|
Short Message |
50 |
|
Daylight saving |
Yes |
|
Self-service Record Inquiry |
Yes |
|
Size |
140(w)*190(h)*30(d)mm |
|
Temperature |
-10℃~40℃ |
|
Operating Voltage |
DC 5V |
|
Certificates |
FCC, CE |
|
Applicable Situation |
Up to 2000 Employees |
|
|
|
