NET-PLV-500AV-PE-MK2




Model: NET-PLV-500AV-PE-MK2

Highslide JS

Click to enlarge


Value Solwise 500AV HomePlug Adapter

  • Single 10/100 Ethernet Port
  • Value Atheros AR7420 chipset
  • Push button for SimpleConnect
  • 1 network cable included
  • 2 year warranty*


The Solwise NET-PLV-500AV-PE_MK2 HomePlug AV 500Mbps can transform your home power lines into a networking infrastructure. HomePlug is a fast and simple way to connect to the Internet with easy connection between your computers, games consoles, laptops, smart phones anywhere in your home where you have a mains socket.

You need at least two HomePlugs to create the connection. Traditionally, one plug is connected to your Internet router, the 2nd plug is placed in the remote area, such as your lounge, study or kitchen. The Plug connected to the router, takes the Internet signal and transfers it along your mains wiring, the 2nd plug takes the signal and distributes it via the Ethernet port directly to your device.

Powered by the Qualcomm Atheros Value AR7420 chipset this Solwise 500AV adapter is compliant with IEEE1901 and Homeplug AV, allowing hassle free compatibility with existing Homeplug AV devices and other suppliers of HomePlug AV devices.

Enhanced Quality of Service (QOS) provides the guaranteed bandwidth required for multimedia including TV over IP (IPTV), higher data rate broadband sharing, Online- Gaming, VoIP Calls, extending Wireless coverage, Audio-Video transmission across the network as well as Network camera connectivity.

The Solwise 500AV adapters all have a configuration push button for a convenient way of creating a secure HomePlug network without the need to use software. Security support is by 128-bit AES Hardware encryption, ensuring the network is secure.

Remember, you will need at least two HomePlug devices to form a HomePlug connection. More HomePlug AV devices can be added to further share your network.

Protocol/Standards IEEE 1901/HomePlug AV Compliant
Co- existence with HomePlug 1.0 Nodes
Compliant to EuP requirements
IEEE 802.3 10/100 Ethernet
IEEE 802.3az support
Data Transfer Rate Up to 500Mbps over powerline
Frequency Band 2MHz to 68MHz band
Quality of Service Priority-based CSMA/CA channel access schemes maximize efficiency and throughput
Integrated Quality of Service (QoS) Enhancements
Hardware Packet Classifiers for ToS, CoS and IP Port Number
Supports IGMP managed multicast session
Security Support 128-bit AES Link Encryption with key management
Chipset Qualcomm Atheros AR7420 + AR1540 chipset
LED Indicators 1 x Power LED (Green color)
1 x Powerline Link/Activity Status LED (Bicolor)
1 x Ethernet Link/Activity Status LED (Green color)
External Connectors 1 x Electrical Power plugs
1 x RJ45 for 10/100 Ethernet
Push Button/Switch 1 x Configuration Push Button (for Simple Connect and Factory Default Reset)
Dimension 85(H) x 53(W) x 30(D) mm
Power Consumption 2.5 Watt (230Vac)
Warranty *2 year warranty on sales from 1st December 2013
