The XR960D4 4 channel DVR is the latest professional DVR from Xvision with advanced features, offering High Definition 960H real-time recording.
The XR960D4 is designed to offer something more than just a standard 960H DVR. Recording in 960H resolution, the DVR ensures that every pixel from the camera will be recorded while also offering remote access to view the DVR from anywhere in the world.
The XR960D4 provides recording in HD 960H, WD1, WHD1 and WCIF in real time and supports PTZ camera operation through RS-485 as well as flexible recording modes, including Alarm Triggered and Motion Detection.
For easy control and setup, the DVR features an On Screen Display (GUI) and can be controlled via the Front Panel, Remote Control or Mouse (both are supplied as standard). In addition, the DVR offers VGA, BNC and HDMI outputs with up to 1080P resolution.
In addition to this, the XR960D4 DVR features the following:
● Recording Rate: WCIF/D1/HD 960H: 100fps Real Time (25fps per camera)
● 4 Audio Inputs
● Remote Access via Smartphone, Tablet, PC and Mac
● Instant Push Video Notifications to iPhone/Android smartphones
● Email Alerts
● Front Panel, Mouse or IR Remote Control
● 3G/4G USB Dongle Support
● VGA, BNC and HDMI monitor outputs
● 4 Alarm Inputs
● 1 Alarm Output
● Accepts 1 Hard Drive of up to 4TB (not included)
● Estimated recording space required per camera per day: 35GB at Highest Quality, 17GB at Medium
and 8GB at Low)
| Brand: |
Xvision |
| Model Number: |
XR960D4 |
| Video Compression: |
H.264 |
| Video System: |
NTSC / PAL |
| Video Input / Output: |
4 CH Input, 1 BNC, 1 VGA,
1 HDMI |
| Spot Output: |
No |
| Audio Input / Output: |
4 CH Input, 1 CH Output (RCA) |
| Display Resolution: |
PAL: 960x576 @ 25fps
NTSC: 960x480 @ 30fps |
| Display Feature: |
Single, Quad, S.E.Q |
| Recording Resolution: |
PAL: D1 Mode: 360x288 (CIF),
720x288 (HD1), 720x576 (D1), 960H Mode: 480x288(WCIF), 960x288 (WHD1),
960x576 (WD1)
NTSC: D1 Mode: 360x240 (CIF),
720x240 (HD1), 720x480 (D1), 960H Mode: 480x240(WCIF), 960x240 (WHD1),
960x480 (WD1) |
| Recording Speed: |
PAL: 25fps
NTSC: 30fps |
| Recording Mode: |
Continuous / Manual / Motion Detection |
| Playback Channel: |
1 / 4 Ch |
| Playback Speed: |
PAL: 25fps
NTSC: 30fps
|
| DVD-RW: |
No |
| Sensor & Alarm I/O: |
Yes |
| IR Extender Port: |
No |
| Network: |
Lan, DHCP, Dynamic IP & DDNS |
| HDD Interface: |
1 SATA HDD, up to 4TB |
| Multiplex Operation: |
Live Display, Record, Playback, Backup and Network |
| USB: |
2 x USB (For mouse and backup / upgrade) |
| PTZ Control: |
Built-in RS485, supports Pelco-P & Pelco-D |
| Mobile XR960 |
CMS - Android and iOS |
| CMS Software: |
64 CH, 256 pcs DVR, no limit to users |
| Web Browser: |
Internet Explorer, Safari, Chrome, Firefox |
| VGA: |
1024x768, 1280x1024, 1366x768, 1440x900, 720P, 1080P |
| HDMI: |
1024x768, 1280x1024, 1366x768, 1440x900, 720P, 1080P |
| Power Supply: |
DC 12V 2000mA |
| Fan: |
Yes |
| On / Off Switch: |
No |
| Remote Control: |
Yes |
| Rack Mount Size in (U): |
1 |
| Housing Dimension (WxHxD): |
230x45x315mm |
|
|
| |
| |
| |
 |
|
