A 3 megapixel camera that offers over 10x the resolution of standard CCTV and IP CCTV cameras, 1.5 times the resolution of FULL HD 1080P cameras and over 3 times the resolution of HD 720P cameras, perfect for use outside any premises requiring a very high resolution IR night vision capable camera.
Produces Real Time images at 2048×1536 (3.0 Megapixel), 1080P (1920x1080), 720P (1280x720) and D1 (704x576) resolution. The camera is able to produces images at twice the resolution of SKY HD!
The Xvision Pixel+ lens is fully adjustable to any viewing angle between 28 and 60°.
The camera has advanced DSP functions allowing it to cope with a wide variety of extreme lighting conditions, like car headlights, making it ideal for Number Plate Recognition up to a maximum range of 5m.
The camera is very versatile thanks to its modern bullet style design and tamper resistant cable managed bracket.
It can be wall or ceiling mounted and has 2 Alarm Inputs, 1 Alarm Output, connection for a microphone and speakers (for 1 or 2 way audio) and an RS485 socket.
Supplied with powerful multi camera recording, viewing and management software for Windows PC's.
View remotely from a PC, Mac or Mobile phone.
| Brand |
Xvision SE |
| Model Number |
XP3000V |
|
Type |
| Style |
Vandal Resistant IP Dome Camera with 20m IR Night Vision |
| Weather Resistant |
Yes |
| Vandal Resistant |
Yes |
| Motorised Panning |
No |
| Motorised Tilting |
No |
| Digital Zoom |
Yes |
| Audio: |
Yes |
| Mounting Type: |
Wall or Ceiling |
| Product Dimensions WxHxD (mm): |
160x118x160 |
| Product Weight |
1.25kg |
| Shipping Dimensions WxHxD (mm) |
210x200x210 |
| Shipping Weight |
1.5kg |
| Warranty |
1 Year Warranty (extendable to 3 years) |
| Camera |
| Image Sensor Type |
1/2.8" 3 Megapixel Progressive Scan Exmor CMOS |
| Image Sensor Resolution |
3 Mega Pixel |
| Minimum Illumination |
0.2 Lux (Colour), 0.01 (B/W), 0 Lux (IR on) |
| Night Vision |
20m IR Night Vision |
| Other Features |
Automatic White Balance
Automatic Gain Control
Automatic Electronic Iris
DNR (Digital Noise Reduction)
Dynamic Night View
True Day/Night
|
| Lens |
4.5-10mm |
| Viewing Angle |
28 to 60° |
| Performance |
| Video Compression |
H264, MJPEG |
| Video Streams |
11 Independent Streams + 2 Region Of Interest Streams |
| Stream Types |
HTTP, RTSP, UDP |
| Video Resolution & Frame Rates |
3 Megapixel (1280x960) at up to 15 fps
1080P (1920x1080) at up to 25 fps
720P (1280x720) at up to 25 fps
D1 (704x576) at up to 25 fps
|
| Networking |
| Network Connection |
RJ45 Socket (10/100 BASE-T) |
| Wi-Fi Support |
N/A |
| Network Protocols Supported |
HTTP, TCP/IP, ICMP, RTSP, RTP, UDP, SMTP, NTP, DHCP, DNS, DDNS,
PPPOE, IP Filter, FTP, Alarm Server |
| Remote Access |
| Browser Support |
Chrome, Internet Explorer, Safari |
| Mobile Phone Support |
Android, Blackberry, iPhone, Nokia (Symbian), Windows Mobile |
| User Authentication |
User Name & Password, IP Filtering |
| Simultaneous Viewers |
Using Unicast: 20
Using Multicast: Unlimited |
| Power Requirements |
| Power over Ethernet |
Yes |
| Operating Voltage |
12V DC |
| Power Consumption |
<10W |
| Other Features |
| Easy Fit |
Optional Xvision Ethernet over Mains adaptor required |
| Motion Detection |
Yes |
| Presets |
No |
| Guard Tours |
No |
| Email Alerts |
Yes |
| On Board Recording |
Yes |
| Alarms |
Yes |
|
|
| |
| |
 |
|
